Performance and features:
1. Each time the fixed flow is supplied to the lubrication area.
2. The flow rate will not be affected by the viscosity of the oil and the length of the oil.
3. It is necessary to use a butter oiling machine with a pressure relief device.
Dimensions:
Type and technical parameters:
| Type |
Theoretical discharge
(cc/stroke)
|
mark | A | Weight (g) |
| DG-000-10 | 0.1 | 0.1 |
66 |
46 |
| DG-000-20 | 0.2 | 0.2 | ||
| DG-000-40 | 0.4 | 0.4 |
1. Lubricate the oil from the pump and push the umbrella valve in the distributor upwards.
2. When the umbrella valve closes the center hole of the core rod, it forces the piston to start to rise against the spring force. Lubricate the previously stored lubricant in the upper chamber.
3. When the piston reaches the top of the upper chamber, the oil discharge is completed at the same time. When the oil pump stops supplying oil, its depressurizing mechanism is automatically opened, so that the pressure oil in the main oil pipe returns oil through the depressurizing mechanism. At this point, the system pressure drops, and the piston in the distributor begins to recover under the action of the spring. When the umbrella valve resumes closing the inlet of the distributor, the piston passes the lubricant stored in the lower chamber through the hole of the core rod.
